Worm Reducer for Dried Powder Press
Worm reducer for dried powder press is a kind of transmission device mainly designed for use in the forming mechanism of dried powder automatic press to facilitate the forming of process metallic materials,ceramic materials,and magnetic material,etc.
Features of Worm Reducer for Dried Powder Press
Our worm reducer for dried powder press is characterized by compact structure, elegant appearance,large pressing force,reliable operation,low running noise,and high efficiency,etc.
Hints for users
1. Only N320 worm gear oil or Mobil SHC 643 synthetic gear oil can be used to lubricate the Reducers.
2. The dimensions and specifications and subject to change without prior notice.
18TU125 Series Worm Reducer for Dried Powder Press
| Type | C.D.(mm) | Ratio | Input power(kw) | Input speed(r/min) | Transmission efficiency(%) | Allowed working oil temperature (℃) |
| 18TU125 | 125 | 10 | 3 | 750 | 92 | 10~100 |
10TU200 Series Worm Reducer for Dried Powder Press
| Type | C.D.(mm) | Ratio | Input power(kw) | Input speed(r/min) | Transmission efficiency(%) | Allowed working oil temperature (℃) |
| 10TU200 | 200 | 12 | 15 | 750 | 91 | 10~100 |
