Miter Gear

Miter gears are one type of bevel gears where the two rotational axes intersect. When speaking of narrow definition of bevel gears with ability to increase or decrease speed, miter gears do not have that ability due to the pair’s same number of teeth. Their purpose is limited to the change in transmission direction. Because they are a type of bevel gears, the basic characteristic of bevel gears exist such as presence of gear forms of straight cut, spiral cut and zerol types.

With straight, conically shaped teeth and a 1:1 speed ratio, miter gears connect two shafts at an angle without changing shaft speed or torque. They're more efficient than spiral miter gears because they create less friction.

For two gears to mesh correctly, they must have the same pressure angle, shaft angle, pitch/module, and number of teeth.

Carbon steel gears have hard, strong, and wear-resistant teeth. They’re best for heavy duty and high-torque applications, such as lifting equipment. However, these gears will rust when exposed to moisture or corrosive chemicals. Some gears have hardened teeth for additional wear resistance; gears with teeth that are not hardened can be hardened to fit your application.

Stainless steel gears won’t rust in damp or wet environments. They’re commonly used in food-processing plants and other areas where frequent cleaning takes place
