Plastic Bevel Gear

Raydafon, Module 1, 20 Tooth, Nylon Bevel Gears Bore Type : Plain Gear Ratio : 2.0 Module : 1 No. of teeth : 20 Direction of Spiral : N/A Shape : B3 Bore (A) : 6.0 (mm) Hub Diameter (B) : 16.0 (mm) Pitch Diameter (C) : 20.00 (mm) Outer Diameter (D) : 22.41 (mm) Mounting Distance (E) : 28.0...

Send Inquiry

Product Description

Raydafon, Module 1, 20 Tooth, Nylon Bevel Gears

Bore Type: Plain

Gear Ratio: 2.0

Module: 1

No. of teeth : 20

Direction of Spiral: N/A

Shape: B3

Bore (A): 6.0 (mm)

Hub Diameter (B): 16.0 (mm)

Pitch Diameter (C): 20.00 (mm)

Outer Diameter (D): 22.41 (mm)

Mounting Distance (E): 28.0 (mm)

Face Width (J): 6.00 (mm)

Hub Width (H): 7.0 (mm)

Total Length (F): 13.78 (mm)

Length from Crown to Back: 8.60 (mm)

Length Of Bore (I): 12.00 (mm)

Plastic Bevel Gear

Gears Plastic Bevel Gear Pinions

Plastic Bevel Gear
