Helical Gear Reducer

“EP series” inline helical gear reducers feature a HP range of ¼-100 HP, 37-147 mm box sizes, 2:1-120:1 speed ratios and a cast iron housing for unquestioned strength and reliability. Offered in a variety of NEMA C-face quill style motor input flange configurations, the “E[” series allows users to easily locate off-the-shelf NEMA motors in lieu of custom gear motors with special first pinion gears.EP s bolt hole pattern, base to center line height, output shaft diameter and usable shaft length match the “R” series of the inline market leader making plant retrofitting a breeze.

Product Features

2:1 - 120:1 ratios (other ratios available as custom orders)

Box sizes 37 - 147

Built for high efficiency, high strength, and low noise

All cast iron housings for unquestioned strength and reliability

Wide range of ratios from 2:1 to 120:1

Horsepower range from 1/4 HP to 100 HP

Gears are precision ground for better rotation and quieter operation

Gearbox flanges are designed to accept NEMA C-Face electric motors

Drop-in for most major European-produced Inline reducer brands

2-year warranty

FR series gear wheel reducer of high precision( geared motors):

FR series gear wheel reducer of high precision is the new product developmented by our factory with advanced technique imported from abroad. It has the merit of small volume, high carrying capacity, wide application scope, and conveniently be installed.

The speed ratio scope is from 1.5:1～5050:1

and export moment is from 16N·m～16000N·m.

FR series

FS series
