Worm Reduction

Precision, 6:1 to 100:1 ratios, torque 1 to 10 Nm and multishaft arrangements

Metric Worm Reduction Gearboxes
Small precision with multi-shaft arrangements

• 6:1 to 100:1
• Torque 1 to 10 Nm
• Drilled and tapped mounting holes on top and bottom
• Flush fitting bearing caps easy to install
• Input shafts mounted on precision ball bearings
• Max. input speed 10000rpm
• Anti backlash version available

Additional Range:
Neckar Worm Gearboxes Type S - 4 sizes available
Smallest gearbox specifications:
• 5:1 to 60:1
• Output Torque: 1.4-2 Nm
• Aluminium housig
• Special steel worm wheel
• Max. load capacity of output shaft 100N radial, 50N Axial
• Max. input speed 5,000 rpm
• Weight: 0.225kg
