Our worm reducer for continuous casting machine is designed with self-locking function and is characterized by compact structure,large transmission ratio,slight vibrating,low running noise, and low power consumption,etc.
Features of Worm Reducer for Continuous Casting Machine
RD series gear reducer is a kind of double stansmission equipment designed with worm and worm wheel.this worm reducer has the features of lading capacity,high efficiency,long service lie,etc.
Its shaft-mounted structuae makes the gear reducer easy to connect to working machinery.Its housing is artistic ic appearance,after prosessed by using resin-coated sand casting.RD-5.5-200 worm reducer for continuous casting machine can be provided with water cooling system,upon request.
Specifications of worm Reducer for Continuous Casting machine
| Type | C.D.(mm) | Ratio | Inputpower(kw) | Input.speed(r/min) | Transmission Efficiency(%) | Allowedworkingoil Temperature(℃) | Application |
| RD-11-4.5-Ⅲ | 125 | 4.5 | 11 | 1500 | 90 | 10~100 | ①* |
| RD-11-4.5-ⅢA | 125 | 4.5 | 11 | 1500 | 90 | 10~100 | ① |
| RD-11-7.5 | 125 | 7.5 | 11 | 1750 | 90 | 10~100 | ①* |
| RD-11-10.5 | 125 | 10.5 | 11 | 1750 | 90 | 10~100 | ① |
| RD-11-12.5 | 125 | 12.5 | 11 | 1750 | 89 | 10~100 | ① |
| RD-4-240 | 180 | 240 | 4 | 1500 | 63 | 10~100 | ②* |
| RD-5.5-200 | 200 | 200 | 5.5 | 1500 | 66 | 10~100 | ③* |
| RD-5.5-80 | 200 | 280 | 5.5 | 1500 | 60 | 10~100 | ③* |
*①Vibration devices
②Storage devices for guide-ingot-bar
③Pulling-Straightening machines
