Poly-V Pulley and Belt drives are ideal where you have space restrictions, high ratio or high torque drives. With only one belt, tensioning is easy and you do not have to worry about matching belts. They will also run quieter than timing pulley and chain drives and do not slip like standard V-Pulleys.

Teeth and Backing Teeth are molded integrally with the backing that protects the tensile members. Both are manufactured from premium quality, synthetic, neoprene rubber that provides exceptional resistance to heat, oil, ozone, and flex fatigue. Precise tooth formation and accurate spacing permit smooth, uniform transmission of power with resistance to tooth jump and shear.

Worm gears are usually used when large speed reductions are needed. The reduction ratio is determined by the number of starts of the worm and number of teeth on the worm gear. But worm gears have sliding contact which is quiet but tends to produce heat and have relatively low transmission...

Worm gears (or wormwheel gears) and worms (or worm drives) are designed to work together to transfer motion between non-intersecting shaft at right angles. Worm gears and worms, which resemble spur gears and screws, respectively, combine to provide a high reduction ratio in a compact gear...

725 Series Gearbox : Application: Final Drive Wheel boxes for all electric drive and Hydraulic powered Center Pivot / lateral move Systems Models Include: 725 – U, 50:1 worm gear ratio: Standard gear ratio for most systems. 725 – UV, 52:1 Worm gear ratio: Select gear ratio to match those...

worms and worm gears provide an effective answer for power transmission applications requiring high-ratio speed reduction in a limited space using right angle (90°), non-intersecting shafts. When properly applied, worms and worm gears provide the smoothest, quietest form of gearing. Because the...
