screw jack
Function:
Worm gear screw jack is a basis jack-up part, accomplanish the functions
such as lifting, drop, push and inverting through worm gear drives screw.
Application Industry:
WSH series worm gear screw jak is applied to the fields such as Aircraft
maintenance platform, machinery, metallurgy, water conservancy,chemical
industry, medical treatment, culture and hygienist etc.
| Type | Structural Style | Model | Output Torque | Screw Diameter | Max.Power | Net Weight (without screw stroke) |
| (KN) | (mm) | (KW) | (KG) | |||
| SWL Screw Jack | I Type | SWL2.5 | 25 | Tr30X6 | 0.55 | 7.3 |
| SWL5 | 50 | Tr40X7 | 1.1 | 16.2 | ||
| SWL10 | 100 | T58X12 | 2.6 | 25 | ||
| SWL15 | 150 | T58X12 | 2.6 | 25 | ||
| SWL20 | 200 | Tr65X12 | 3.7 | 36 | ||
| II Type | SWL | 250 | Tr90X16 | 4.8 | 70.5 | |
| SWL35 | 350 | Tr100X18 | 6 | 87 | ||
| SWL50 | 500 | Tr120X20 | 7.5 | 420 | ||
| SWL100 | 1000 | Tr160X23 | 15 | 1010 | ||
| SWL120 | 1200 | Tr180X25 | 17.5 | 1350 |
We are leading organization in this domain actively engaged in providing a wide array of Screw Jack. Used for supporting a work piece, these screw jacks are well tested on numerous quality parameters for making certain its flawlessness. Our screw jacks are manufactured with the finest quality steel sophisticated techniques in line with the market standards by our skilled professionals.
Screw Jack is stable robust and free from wear and tear.
The height adjustment is made through threaded spindles which are self-locking
Threads are trapezoidal
Holding plate fixes the position of adjustable height block Horizontally or vertically
Space required is minimum
Tommy bar is an auxiliary tool for easy mounting and adjustment under load
Q: How long is your delivery time ? What is your terms of payment ?
A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment.
Q: What is the exact MOQ or price for your product ?
A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation.
